External Parameter Definitions in Teigha BIM

Teigha BIM supports external parameter definitions, which are entities stored in external text files and not included in project/family documents but can be imported into documents. Parameter elements of the ParamElemExternal class store the guid of an external parameter definition.

rvt rfa getting started

Using the New Measurement Functionality when Exporting to Adobe® .pdf Files

Teigha’s PDF Export functionality now supports accurate measurements of CAD data in exported .pdf files. Let’s look at how it can be used and how it looks in a .pdf file.

pdf Example export

Creating Textured Materials using Helper Classes for Assets in Teigha BIM

Teigha BIM supports fourteen default materials: Ceramic, Concrete, Generic, Glazing, Hardwood, MasonryCMU, Metal, MetallicPaint, Mirror, PlasticVinyl, SolidGlass, Stone, WallPaint and Water. Each material has a rendering asset, which contains material rendering properties, such as color, finishing style, bumping and so on. Textures can also be defined for a material. Almost all default materials support textures — textures are not only for Metal, Mirror and Water materials. A texture can be used as a ‘skin’ of an element, and it’s also possible to define finishing effects for the material using bitmap files. To access or set up textures of a material, the appropriate properties should be used. For example, a texture can be set for the Stone material in the ‘stone_color’ property, but also the Stone material has ‘stone_pattern_map’ which defines a finishing style of the material.

Example rvt rfa

Using Collada Import with Teigha BIM

COLLADA is short for Collaborative Design Activity. DAE files are based on the XML COLLADA format, and they are used by various graphics programs to exchange digital assets under the same format. Each file consists of a set of elements that are images, lights, geometries, effects, materials, cameras, etc.

b-rep rvt rfa

Working with .sat and .sab Files in Teigha

Teigha uses .sat and .sab files to define 3D geometry of 3D entities (OdDbRegion, OdDbBody, OdDb3dSolid, OdDbSurface, etc.).

getting started geometry conversion

Creating Textured Materials using Helper Classes for Assets in Teigha BIM

Teigha BIM supports fourteen default materials: Ceramic, Concrete, Generic, Glazing, Hardwood, MasonryCMU, Metal, MetallicPaint, Mirror, PlasticVinyl, SolidGlass, Stone, WallPaint and Water. Each material has a rendering asset, which contains material rendering properties, such as color, finishing style, bumping and so on. Textures can also be defined for a material.

rvt rfa Example

Cross Sections and Views in Teigha PRC

With Teigha PRC it is possible to create named views with or without cross sections. To include a custom view in a .pdf document, you must create a special view object in Teigha PRC and set up a camera for the view.

prc pdf export

Teigha Civil’s 3D Feature Line Entity

There are two ways of drawing feature lines: by 2D polyline (OdDbPolyline object) and by 3D polyline (OdDb3dPolyline object). The difference in elevation values affects all site feature edge points. If all elevations are equal, the feature line will be drawn via an OdDbPolyline entity, else via OdDb3dPolyline. In the 2D case, OdDbPolyline consists of eLine and eArc edges of type (AECCSiteEdge::Type). The OdDb3dPolyline entity consists of eLine types only and for arcs interpolation purposes uses tessellation (short, straight line segments) based on explode functionalities.

civil getting started

Using the OdPrcCreate Example

The main Teigha PRC example for “how to create” is the OdPrcCreate example located in the \Prc\Examples\OdPrcCreate folder. The release package includes a prebuilt OdPrcCreate.exe application in the “exe” folder. Also a project file is available in the release packages (for Microsoft® Windows®). So it is possible to start the prebuilt application or debug it using Microsoft Visual Studio.

prc Example

Attaching and Validating Digital Signatures for .dwg Files

With the new release of Teigha 4.3.1, you can attach digital signatures to your .dwg files and validate a .dwg file’s digital signature. A digital signature indicates who the file came from and the file’s state when the digital signature was created, and validation confirms this information.

getting started Example
