Domains and Workflows
Adaptable to a wide range of application areas and workflows, including construction, BIM, plant & process, FEA, CFD, PDM, PLM, general CAD and more.
Visualize can be integrated into any type of web-based system, including configurators, PLM & PDM systems, viewers and markup editors. It can query the original model based on selected objects, and can be customized to interact with databases and other external systems.
Unified Multi-Format Viewers
Visualize any supported format through a single, unified workflow. Add markup and custom views, and export to VSF (Visualize Stream Format) for archival and fast retrieval.
Combine multiple models from any supported formats into a single view, similar to capabilities provided by Autodesk® Navisworks®.
Designed for a wide variety of tasks and problem domains.
An optimized scene graph stores the primary model, while markup and temporary graphics are stored separately for fast redraw.
Visualize is designed to handle large data sets efficiently. Spatial indexing, level of detail, and other optimization techniques provide fast performance.
Streaming, memory limiting and other techniques provide real-time responsiveness in web-based applications.
Visualize large models with ease.
Real-time detection of collisions between model elements. Under development, estimated availability December 2018.
Use multiple cutting planes to expose and inspect interior sections of a model. Under development.
Automatically create an exploded view of a model for product documentation and other purposes. Under development.
Precisely measure distances in any model. Under development.
Collision detection, cutting planes and more.
|.rcs (Autodesk® Recap®)|
|PDF (3D PRC-based)|
|VSF (Visualize Stream Format)|
*Requires an additional annual licensing fee
Visualize is compatible with all formats supported by ODA.
Part of Standard ODA Membership
Visualize is included in all ODA membership levels, at no additional cost beyond the standard membership fee.
Web Applications and SaaS
Web applications (including SaaS) are permitted under the ODA Sustaining, Founding and Corporate membership levels (no limits on distribution).
ODA offers free technical support for all membership levels.
As a non-profit technology consortium, ODA develops engineering solutions at cost, for the benefit of the industry. See about oda for more details.
Tiered licensing with transparent pricing.
